The project is envisaged to create tourist facilities infrastructure to enhance tourism activities and to strengthen the economy of city.
Phase-1
1. Parking plaza
2. Mid-way zone
3. Mahakaal theme park
4. Mahakaal Corridor
5. Nutan school complex
6. Ganesh nagar school
7. Multi-level Car Parking
MRIDA
Smart Road
Smart Road – (Street Furniture with Underground Ducting)
Central business district of Ujjain city is a place of mixed use development planned in a grid iron pattern. It is situated in the heart of the city and it became a commercial hub for the city. It is a place which attracts heavy crowd and traffic. Parking, dedicated pedestrian lanes and vending zones are the major issues of this area.
In order to solve all these issues we proposed underground ducting for the strengthening of infrastructure, street furniture to provide beauty & uniformity to the roads and ICT components to make it smart.
The development of Smart Road includes 1.2 km length of road with Tower Chowk (Heritage Building and a landmark).
The major components of the project are:
- Uniformity of the roads & Road markings.
- Junction improvement.
- Dedicated lanes for pedestrian as well as cycling.
- Development of MUZ (Multi Utility Zone) which includes on street 2-wheeler parking, dedicated vending zone, sit-out spaces & landscaping.
- Bio Toilets.
- Cycle docks.
- Smart Bus shelters.
- Dedicated lanes & parking for auto-rickshaws & taxis.
- Four wheeler parking at cut chowks.
ICT components like Smart poles, Security Cameras, etc.
Mayur Van
Ujjain has been the shelter for a number of Peacocks, Birds, Butterflies, and Snakes. It also provides a very soothing human interaction with nature. Currently due to disturbance in biodiversity because of increased population and development, it has become a challenging task to both conserve the ambiance and ensure safety of the species.
In view of the above situation, Ujjain Smart City and Ujjain District Forest Authority in a coordinated way proposes to implement Mayur Van (Peacock Park). The project focusing towards urban forestry, bio-diversity and ecological conservation, environmental education coupled with adventure and recreation for the visitors promotes Eco-Tourism.
The Project is proposed on 6.7 Ha. land which is situated on Kothi Road near Collectorate Bhawan, Ujjain, in which 1.3 Ha. will be used as recreational and adventurous part for visitors and rest will be the dense forest.
The concept for the project is to develop few spaces for the visitors for recreation and environmental education without disturbing the living species in the forest. Therefore, all the physical development is done through locally available material and dense landscape with diffused night lighting. It will be a perfect example of vernacular architecture.
Underground Ducting
Under Ground Ducting is an important upcoming project under Smart city plan. The project will focus on Investigation, survey, detailed designing and retrofitting & reconstruction of Roads . which may also consist of up-gradations, augmentation, storm water drainage & retrofitting of open storm water drains. Enhancing and developing of footpath along with road markings and improved traffic signage . Underground electrification with allied infrastructure, retrofitting of water supply line in ABD Area
Retrofitting and reconstruction of Roads in ABD Area Consisting:
- Storm Water Drainage
- Underground Electrification
- Duct for OFC Network
- Duct for Gas pipeline
- Footpath along with Cross Section of Road
- Total Length – 25 Km
- Project Cost – Rs 250 Crore
- Status – Draft DPR / RFP Prepared
List of Selected Roads
S.No. | Name of Road | Width | Length |
R1 | Preety Nagar to Bima Hospital Chauraha | 8M | 1043 M |
R2 | Ganeshwari Mata Mandir Chauraha to Bridge Zero Point | 12M | 459 M |
R3 | Sandhipani Nagar Chauraha to Shree Nageshwar Parshawanath | 12M | 263 M |
R4 | Shree Nageshwar Parshawanath to Bailpateshwar Tiraha | 12M | 403 M |
R5 | Shree Nageshwar Parshawanath to Koyal Phatak Chauraha | 10M | 454 M |
R6 | Dewas Gate Chauraha to Chamunda Mata Cahuraha | 12M | 835 M |
R7 | Hanuman Mandir Tiraha to Hanuman Prasad Fuel Station | 8M | 154 M |
R8 | ABD Boundary to Indore gate Chauraha | 24 M | 1715 M |
R9 | Dewas Gate Chauraha to Daulatganj Chauraha | 12M | 482 M |
R10 | Dudh Talai teraha to Tilak Marg | 6-8M | 269 M |
R11 | Indore Gate to Daulat Ganj Chauraha | 15M | 333 M |
R12 | Daulatganj Chauraha to Mhakaleshwar Temple | 10M | 880 M |
R13 | Indore Gate to Hari Phatak Bridge | 18M | 623 M |
R14 | Nagori Mohalla Chauraha to Gada Pulia Chauraha | 6 -8M | 623 M |
R15 | Upkeshwar Chauraha to Beagm Bagh Chauraha | 6 -8M | 492 M |
R16 | Shree Kabir Ashram Tiraha to Mahakal Ghati Chauraha | 6 -8M | 315 M |
R17 | Yanti Guest House to Bhadoria Car Parking | 6 -8M | 107 M |
R18 | Mahakal Ghati Chauraha to Rudrasagar | 18M | 311 M |
R19 | Mahakaleshwar Chauraha to Hari Phatak Bridge | 15M | 545 M |
R20 | JaiSinghpura Marg to Triveni Museum Tiraha | 8M | 731 M |
R21 | Triveni Museum Tiraha to Chanalal Jaisingh Chauraha | 6 -8M | 338 M |
R22 | Rudrasagar Road 1 | 12M | 773 M |
R23 | Rudrasagar Road 2 | 12M | 979 M |
R24 | Bhagatsingh marg double lane to Radha Swami Asharam | 8M | 736 M |
R25 | Char Dham Mandit to Shri Hatkeshwar Dham | 15M | 709 M |
R26 | Bhagar Singh Marg to Harsiddhi Chauraha | 18M | 1208 M |
R27 | Harisidhi Marg to Shree Laxmi Narsingh Temple | 12M | 166 M |
R28 | Begambag Colony to Harisidhi Churaha | 8M | 422 M |
R29 | Harisidhi Churaha to Police Thana Mahakaal | 8M | 88 M |
R30 | Mahakaal Chauraha to Kamri Marg Chauraha | 8M | 592 M |
R31 | Tanki Chauraha to Anant Nagar Chauraha | 8M | 894 M |
R32 | Anant Nagar Chauraha to KD Gate | 8M | 633 M |
R33 | Dani Gate to Ram Ghat | 8M | 269 M |
R34 | Vighnharta Ganpati Mandir to Shri Venkteshwar Dharamshala | 8M | 501 M |
R35 | Shri Venkteshwar Dharamshala to Kartik Chawk | 8M | 299 M |
R36 | Chaubees Khamba to Vighnharta Ganpati Mandir | 6-8M | 207 M |
R37 | Shivaji Tiraha to Police Thana Mahakaal | 6-8M | 162 M |
R38 | Ma Chamunda Traders to Mahadev Uphar Gruh | 6-8M | 56 M |
R39 | Gudri Chauraha to Mansarovar Guest House | 6-8M | 561 M |
R40 | Pandriba Tiraha to Shiv Temple | 6-8M | 372 M |
R41 | R41 to Ram Ghat | 6-8M | 505 M |
R42 | Kartik Chawk to Dani Gate | 6-8M | 158 M |
R43 | Shri Venkteshwar Dharamshala | 6-8M | 119 M |
R44 | Chatri Chawk to Kanthal Chauraha | 6-8M | 403 M |
R45 | Tanki Chawk to Teliwada Chauraha | 6-8M | 456 M |
R46 | Tanki Chawk to RNT Road Chauraha | 6-8M | 209 M |
R47 | Nikas Chauraha to K D Gate Chauraha | 6-8 M | 532 M |
R48 | KD Gate Chauraha to Kamri Marg Chauraha | 10M | 414 M |
R49 | Gopal Mandir to Chattri Chauraha | 12M | 94 M |
R50 | Around Chatri Chawk | 8M | 204 M |
R51 | Kanthal Chauraha to Nikas Chauraha | 10M | 413 M |
Typical Cross Section of Sub Surface Infrastructure Details for 24m to 18m wide roads
She Lounge
She Lounge (with amenities such as smart public toilets, ATMs, kiosks, solar panels, Wi-Fi hotspots, mobile phone booster towers, mobile phone charges, etc.)will become a hallmark of the city.
Essential features of She Lounge :
- All design of She Lounge and other amenities will ensures universally accessible design.
- It will ensure essential services for users such as adequate Treated Potable Water for drinking and general cleanliness of the She Lounge, adequate power supply for proper lighting of the She Lounge and commercial activities; public conveniences such as smart toilets and kiosks, wherever possible.
- Adequate measures for safety and security of Users, including but not limited to deployment of security personnel and gadgets such as CCTV etc. The Concessionaire is required to employ trained professionals to operate and maintain the She Lounge and other amenities system.
- Structurally sound and aesthetically appealing Users facilities such as clock, bus route maps, information on Ujjain, etc.
- Adequate and comfortable seating facilities for Users
- Special arrangements for the differently abled such as voice guidance system to help the Users to operate the She Lounge without manual assistance, provide ramps, hand rails, beepers etc. for the differentially abled Users and the senior citizens for accessing each of the component of the She Lounge
- Essential services such as soaps, napkins, dust bins etc. for Users of the smart public toilets at such She Lounge
- Precaution for environmental and social safeguards in accordance with applicable norms and guidelines
- She Lounge during the Concession Period, including regular cleaning of the She Lounge and its surrounding areas, monitoring and functioning of Users’ amenities, handling emergency situations, functioning of information and communication systems, availability of basic infrastructure requirements such as electricity for lighting purposes, proper drainage, removal of municipal solid waste, and telecommunication etc. The Concessionaire is to specifically ensure that the She Lounge and all amenities are clean and free of debris, garbage through regular monitoring, maintenance and solid waste collection.
Auditorium
A 1500 seater auditorium is proposed at Samajik Nyay Parisar. Total site area is 3.7 hectares and proposed built-up area is 1 hectare.
OBJECTIVE
- To look at wider perspective of ‘HABITAT’ as a public space. It therefore broadens the range of areas and activities, from more intense activity zones like meeting, conference, seminars to contemplative zones like gardens, cafeterias and food courts.
- To develop a democratic space to benefit all sections of society by including community related functions and activities.
- To make financially self-sustainable entities to generate enough revenue for maintenance through commercial zones.
STRATEGIES
- To hold the site together through various visual elements or sculptures or art installations.
- To bind various components and entities by thoughtful and coherent design.
- To create pause points and nodes through experiential/ transitional spaces.
- To provide recreational spaces for various activities inviting public interaction and exploration.
- To provide leisure space for public to socialize and unwind, such atmosphere will add vibrancy and life to a city.
FUNCTIONS
- Formal areas – Annual general meetings, Board/ Committee meetings, Shareholder management, meetings, Presentations, Trainings, Conferences, Lecture Hall, Presentations, Seminars,
- Entertainment / culture related – Opera hall, Concert hall, Dance theatres, Drama theatres, Musical theatres,
- Informal Areas – Major Expo, Public Exhibitions, Smart City Exhibition, Educational Programme, Cultural Programme, Art galleries, Visitor centers,
- Recreational Area – Open Air Theatre, Parks, Handicraft zone, Workshop areas, Hawker zone, Community functions
BUILDING COMPONENTS INCORPORATING ALL FUNCTIONS
- Auditorium 4210 Square meter
- Multipurpose hall – 520 Square meter
- Stepped well
- Amphitheatre
- Hawker’s zone
- Covered craft market
- Bamboo pavilion
- Lotus pond
- Biodiversity park
- Parking – 250 cars
Swimming Pool
Construction of Olympic size Swimming Pool (50m. x 25m.) with Kids Pool (12m. x 10m.) including all plumbing, pumping & filtration units and electrical works complete including Open Air Sitting & Service Area, Swimmers Block, Facade Wall, Dismantling and Restoration of Existing Structures, external development including creation of Natural Pool with Landscaping & Approach Road with side drains, Sports & Gym cum Admin Block and compound Wall including Operation and Maintenance for 5 Years
Concept:
- Scope of creation of public swimming pool with a elements of heritage importance.
- Scope of using existing water body as natural water body replenishing system.
- Enhance Existing vegetation for aesthetic purposes.
Current Status:
- Design proposal have been prepared and under discussion with USCL.
- Total Station Survey under progress at the project site.
- Project shall be executed under convergence from UMC , tentative project cost of Rs 5 Cr.
