Underground Ducting

Under Ground Ducting is an important upcoming project under Smart city plan. The project will focus on Investigation, survey, detailed designing and retrofitting & reconstruction of Roads . which may also consist of up-gradations, augmentation, storm water drainage & retrofitting of open storm water drains. Enhancing and developing of footpath along with road markings and improved traffic signage . Underground electrification with allied infrastructure, retrofitting of water supply line in ABD Area

Retrofitting and reconstruction of Roads in ABD Area Consisting:

Storm Water Drainage
Underground Electrification
Duct for OFC Network
Duct for Gas pipeline
Footpath along with Cross Section of Road
Total Length – 25 Km
Project Cost – Rs 250 Crore
Status – Draft DPR / RFP Prepared

List of Selected Roads

S.No.	Name of Road	Width	Length
R1	Preety Nagar to Bima Hospital Chauraha	8M	1043 M
R2	Ganeshwari Mata Mandir Chauraha to Bridge Zero Point	12M	459 M
R3	Sandhipani Nagar Chauraha to Shree Nageshwar Parshawanath	12M	263 M
R4	Shree Nageshwar Parshawanath to Bailpateshwar Tiraha	12M	403 M
R5	Shree Nageshwar Parshawanath to Koyal Phatak Chauraha	10M	454 M
R6	Dewas Gate Chauraha to Chamunda Mata Cahuraha	12M	835 M
R7	Hanuman Mandir Tiraha to Hanuman Prasad Fuel Station	8M	154 M
R8	ABD Boundary to Indore gate Chauraha	24 M	1715 M
R9	Dewas Gate Chauraha to Daulatganj Chauraha	12M	482 M
R10	Dudh Talai teraha to Tilak Marg	6-8M	269 M
R11	Indore Gate to Daulat Ganj Chauraha	15M	333 M
R12	Daulatganj Chauraha to Mhakaleshwar Temple	10M	880 M
R13	Indore Gate to Hari Phatak Bridge	18M	623 M
R14	Nagori Mohalla Chauraha to Gada Pulia Chauraha	6 -8M	623 M
R15	Upkeshwar Chauraha to Beagm Bagh Chauraha	6 -8M	492 M
R16	Shree Kabir Ashram Tiraha to Mahakal Ghati Chauraha	6 -8M	315 M
R17	Yanti Guest House to Bhadoria Car Parking	6 -8M	107 M
R18	Mahakal Ghati Chauraha to Rudrasagar	18M	311 M
R19	Mahakaleshwar Chauraha to Hari Phatak Bridge	15M	545 M
R20	JaiSinghpura Marg to Triveni Museum Tiraha	8M	731 M
R21	Triveni Museum Tiraha to Chanalal Jaisingh Chauraha	6 -8M	338 M
R22	Rudrasagar Road 1	12M	773 M
R23	Rudrasagar Road 2	12M	979 M
R24	Bhagatsingh marg double lane to Radha Swami Asharam	8M	736 M
R25	Char Dham Mandit to Shri Hatkeshwar Dham	15M	709 M
R26	Bhagar Singh Marg to Harsiddhi Chauraha	18M	1208 M
R27	Harisidhi Marg to Shree Laxmi Narsingh Temple	12M	166 M
R28	Begambag Colony to Harisidhi Churaha	8M	422 M
R29	Harisidhi Churaha to Police Thana Mahakaal	8M	88 M
R30	Mahakaal Chauraha to Kamri Marg Chauraha	8M	592 M
R31	Tanki Chauraha to Anant Nagar Chauraha	8M	894 M
R32	Anant Nagar Chauraha to KD Gate	8M	633 M
R33	Dani Gate to Ram Ghat	8M	269 M
R34	Vighnharta Ganpati Mandir to Shri Venkteshwar Dharamshala	8M	501 M
R35	Shri Venkteshwar Dharamshala to Kartik Chawk	8M	299 M
R36	Chaubees Khamba to Vighnharta Ganpati Mandir	6-8M	207 M
R37	Shivaji Tiraha to Police Thana Mahakaal	6-8M	162 M
R38	Ma Chamunda Traders to Mahadev Uphar Gruh	6-8M	56 M
R39	Gudri Chauraha to Mansarovar Guest House	6-8M	561 M
R40	Pandriba Tiraha to Shiv Temple	6-8M	372 M
R41	R41 to Ram Ghat	6-8M	505 M
R42	Kartik Chawk to Dani Gate	6-8M	158 M
R43	Shri Venkteshwar Dharamshala	6-8M	119 M
R44	Chatri Chawk to Kanthal Chauraha	6-8M	403 M
R45	Tanki Chawk to Teliwada Chauraha	6-8M	456 M
R46	Tanki Chawk to RNT Road Chauraha	6-8M	209 M
R47	Nikas Chauraha to K D Gate Chauraha	6-8 M	532 M
R48	KD Gate Chauraha to Kamri Marg Chauraha	10M	414 M
R49	Gopal Mandir to Chattri Chauraha	12M	94 M
R50	Around Chatri Chawk	8M	204 M
R51	Kanthal Chauraha to Nikas Chauraha	10M	413 M

List of Selected Roads

Typical Cross Section of Sub Surface Infrastructure Details for 24m to 18m wide roads
